1mm simple and cheap cutting machine sell to Madagascar

Short Description:

1.Description of 1mm simple and cheap cutting machine sell to Madagascar Automatic steel coil piece to piece sheet cutting machine line is using in wholesale sheet business. We use this machine to cut to pieces and sell them to client. This cutting machine can cut length one by one. There are 2 stations for flatten the material which make coil straightly input to cutting machine. It is using for bring the steel coil running and do not break the surface of steel coil. Some clients but piece to...


  • Raw material: PPGI&GI&ALZN
  • Control system: PLC Control system
  • Port: Tianjin/Shanghai/Beijing
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    FAQ

    Product Tags

    1.Description of 1mm simple and cheap cutting machine sell to Madagascar

    Automatic steel coil piece to piece sheet cutting machine line is using in wholesale sheet business. We use this machine to cut to pieces and sell them to client. This cutting machine can cut length one by one.

    There are 2 stations for flatten the material which make coil straightly input to cutting machine. It is using for bring the steel coil running and do not break the surface of steel coil.

    Some clients but piece to piece cutting machine for barrel galvanized corrugated sheet roll forming machine. And popular length are 8ft/10ft and 12 ft. Because if they pieces from the steel coil factory, price is very high. So they buy cutting machine for themselves. They can cut any length of roof panel what they need.

    Capacity of cutting machine: the normal speed is same with the roof tile roll forming machine. So 8-12m/min. If you need this speed, you can use manual decoiler. If you wanted high speed, machine price will be added and you must choose electric decoiler or hydraulic decoiler. Because the speed is so that that the shaft can not bring the steel coil very well. So the length is not correct.

    If you want to know more details of cutting machine, contact us directly.

    Remark: if your need other thickness, please check we other type cutting machine

    2.Working process

    The complete  line includes decoiler, forming machine, computer controlling system and run out tables. Our machines are equipped with a computer controlling system to keep products accurate.

    QQ截图20170329205629

    3.Diameter of 1mm simple and cheap cutting machine sell to Madagascar

    NO

                Type

    Specification

    1

    Raw material Type PPGI or GI
    Feeding width As customer request
    Thickness 0.3-0.8 mm

    2

    Decoiler Operation Manual
    Weight apacity 5 Tons

    3

    Main body Roller station 3 row
    Diameter of shaft 70 mm
    Shaft material 45# with 0.05mm chrome
    Roller material 45# with 0.05mm chrome
    Type Chinese type
    Frame 300mm C-beam
    Frame thickness 16 mm
    Material Cr 12
    Operation Hydraulic automatic
    Working speed 8-12 m/min

    4

    Power Driving way Chain 1 inch
    Main motor 5.5 KW
    Voltage 380V/50HZ, 3 phase

    5

    Control box Electric box PLC control system, inventer
    PLC brand Delta made in Taiwan
    Inverter brand Delta made in Taiwan
    Language Chinese and English












  • Previous:
  • Next:
  • 1 Q: Are you a manufacturer?
        A:Yes, we are manufacture with four branches factory

    2. Q: How to order my machine
         A: Send me your design drawing if you have.
    Or tell me your design idea. Our engineer will design it as your needs.

    3. Q: What details of the machine you should get from me.
         A: I will confirm all details with you, such as the voltage in your city.

    4. Q: I am new in this field. How could i understand the machine very well
         A: Contact with us,24 hours online service side.

    5. Q: I receive a lot of quotations, they are big difference, How could i choose?
         A:we have many easy ways to solve it. Fox example, we can teach you how to find the   Traders out. Just contact us.

    6.Q: Can you give me one suggestion for ordering the machine.
       A: No problem. Do not trust your eyes when you see beautiful pictures of machines or factories. More when you contact.

    7. Q: Can you use other brand of spare parts for me if i want.
         A: No problem if you want to pay the money.
